Product Parameters

• Photometrics

• Light Source: 960 pcs LEDs(480X1.5W RGB + 480X0.5W White)

• Beam Angle: 60°

• Field Angle: 125°

1. Key Features

2. Pixel Matrix: 4 x 15

3. Strobe: 0 ~ 30Hz

4. Dimming: 4 dimming curve modes

• Control

• Protocol: DMX, ArtNet，KlingNet,RDM

• DMX Channels: 12/28/44/244

• Built-in Programs: Yes

1. Power

2. Mains: 100 - 240 VAC, 50/60 Hz

3. Consumption: 1000W (full-on constant output)

4. Consumption: 1200W (peak instant strobe)

• I/O

• Power connections: IP65 PowerKon In/Out

• Data connections: IP65 XLR In/Out for DMX,

• IP65 EtherCon for ArtNet

1. Housing

2. Material Diecast Aluminum

3. IP rating: IP65

• Thermal

• Cooling Variable speed fans

• Ambient operating temps: -20° ~ 40°C

1. Physical

2. Dimensions: 510 x 250 x 268 mm

3. Weight: 12 KG
