Product Parameters

• TECHNICAL SPECIFICATION

• Length： 39.4” (1002mm)

• Width： 5.12” (130mm)

• Height (w/o yoke)：8.27” (210mm)

• Weight： 17kg

• POWER

• Operating Voltage：100-277VAC 50/60Hz

• Fus：12A 250V slow-blow (5x20mm)

• Power consumption：1400W

• LIGHT SOURCE

• LEDs：108*10W RGBW LEDs divided into 12 pixels

• Color：RGBW

• Beam spread：36°

• Intensity control：16bit or 8bit

• Refresh rate：From 400 to 24K

• AVERAGE COLOR WAVELENGTH

• Red：625 nm

• Green：530 nm

• Blue：460 nm

• White：>5700K

• Refresh rate：1200Hz

• THERMAL

• Max. ambient temperature： +104°F (+40 °C)

• Min. ambient temperature：-4 °F (-20 °C)

• Cooling：air cooled – fan

• CONTROL / PROGRAMMING

• DMX input：locking 5-pin XLR male socket

• DMX output：locking 5-pin XLR female socket

• DMX pin config：pin 1 shield, pin 2 (-), pin 3 (+), pin 4 n/a, pin 5 n/a

• Control：RDM, DMX-512, ArtNet,sAcn, Manual Mode

• DMX Channels：9,19,53

• Power Connector： Input: PowerCon 20A

• IP RATED

• IP Rated：IP65
